1550nm 4X4 Single-mode Fiber Switch Small Module Optical Switch

Product ID: 1579

$333.00 – $667.00

1550nm 4X4 Single-mode Fiber Optical Switch 10MS Small Module Optical Switch

[Features]
Low insertion loss
High stability

[Specifications]

Prameter Unit Value
Port Type 4X4
Insertion Loss dB ≤1.3
Return Loss dB ≥55 (MM fiber: ≥30dB)
Repeatability dB ≤±0.02
Crosstalk dB ≥55
Polarization Dependent Loss dB ≤0.05
Wavelength Dependent Loss dB ≤0.25
Temperature Dependent Loss dB ≤0.25
Switch Time ms ≤5
Life Span time ≥3*10^7
Voltage V DC 3V/5V
Current mA 40~50
Operating Temperature ℃ -20 ~ +60
Storage Temperature ℃ -40 ~ +80
Max Withstand Power mW 500


optical switch


optical switch

SM optical switch

SM optical switch

SM optical switch

SM optical switch

SKU: P1579 Category: Tag:
Weight 2.96 kg
Port Type

1X4, 1X8, 4X4
