532nm 100mW 0.1nm Narrow Line-width Laser Fiber Output Raman Laser

532nm 100mW 0.1nm Narrow Line-width Laser Fiber Output Raman Laser

The 532nm Raman laser has a stable spectrum and a small line width, making it ideal for Raman and sensing applications. This type of laser is optically coupled with a fiber output at 532nm, which makes it more convenient to use with laser spectrometers and integration.

Notes:
This is a custom product, if you need other output power, or have special requirements, please contact us.

Lead Time: 3~4 weeks

[Features]
1.Spectral stability(<3%)
2.Small line width(0.1nm)

[Applications]
1.Raman spectrum
2.Sensing

[Specifications]
Wavelength: 532nm
Output Power: 100mW (@ Fiber output side, and 0~max power adjustable)
Fiber Connector: FC/PC or SMA-905 (choose)
Fiber Type: MM Fiber
Fiber Length: 1 meters
Fiber Diameter: 100μm
Output Stability (RMS):<5% over 2 hours
Modulation: 0~10KHz TTL
Operating Temperature: 0°C-45°C
Storage Temperature: -40°C-85°C
Warming Time: <5 minutes
Service Life: >5000 hours
