635nm 100mW Line laser system Customizable Fan angle

635nm 100mW Line laser system Customizable Fan angle

[Features]
1. High power stability.
2. Small size
3. Applicable temperature is wide.
4. Energy uniformity

[Applications]
1. 3D scanning
2. Machine vision
3. Slit detection
4. Trajectory monitoring

[Specifications]
Product Name: 635nm Line Laser
Lead Time: 1~3 weeks, Custom product available!
Output Wavelength: 635±2 nm
Output Power: 100mW
Laser Shape: Line
Fan Angle: Default 90°(Customizable 10°, 30°, 45°, 50°, 60°, 75°, 85°, 90°)
Line Thickness: Random by default (working distance can be customized)
Operating Mode: CW or Modulation
Pointing Stability: <0.05mrad
Beam Height: Near 25mm
Power Stability: <±3% per 4 hrs
Temperature Stabilizing: TEC
Warm Up Time: <2 minutes
MTTF(mean time to failure): 10,000 hrs
Laser Head Dimension: Near 100(L)*40(W)*50(H)mm³
Power Supply: Lab Adjustable power supply
Modulation: 0~30khz Analog or TTL
Warranty: 1 Year

[Package Include]
1 x 635nm laser head
1 x Power supply
